SS19 SUBSEA LEVER HOIST

Main Features

- Suitable for use in multi-immersion applications
- DNV GL Verification tested according to NORSOK R-002
- 800kg, 1.6t, 3.2t, 6.3t, 10.0t, 15.0t and 20.0t capacities available
- Globally Patented Quad Cam Pawl System – proven reliability
- Thousands of hours of empirical evidence as proof of design
- DU® self-lubricating metal polymer bearings
- Phosphor bronze bearings
- Equipped with our unique intelligent Torsion Brake System- One-piece construction pinion gear
- Meets and exceeds IMCA DO28 Rev 1 guidance notes for offshore lever hoists
- Light load protection at 2% of the rated capacity
- Adaptable to use both inverted and horizontally
- Full face gasket provides brake chamber protection from outside contamination
- Fully Corrosion protected body and components to ensure reliable long-term use
- Over 1500 hours protection to ASTM B117 conditions
- Adjustable chain end anchorage specifically designed to the contours of the hoist
- Available with slipping clutch overload protection




"Il Titolare non si assume alcuna responsabilità nei confronti degli utenti naviganti del sito in merito al contenuto di quanto pubblicato sul sito stesso (accuratezza e completezza delle informazioni fornite o riguardo un eventuale uso che terzi ne potranno fare). Il materiale e le suddette informazioni comprese nel sito sono soggette a cambiamenti o aggiornamenti, apportabili in qualsiasi momento, da parte del Titolare."

"The Owner assumes no responsibility towards users navigating his site with regard to the content published on the site itself (accuracy and completeness of the information provided or regarding any use that third parties may make of it). All the material and the aforementioned information included in this site are subject to changes or updates, which can be carried out at any time by the same Owner."

English

Reviews for SS19 SUBSEA LEVER HOIST

SUBSEA LEVER HOIST SS19 0,8 TSUBSEA LEVER HOIST SS19 1,6 TSUBSEA LEVER HOIST SS19 3,2 TSUBSEA LEVER HOIST SS19 6,3 TvSUBSEA LEVER HOIST SS19 10 TSUBSEA LEVER HOIST SS19 15 TSUBSEA LEVER HOIST SS19 20 T
